Mining Electric Anti-Corrosion Centrifugal Slurry Pump

Heavy abrasive slurry pumps description:

-Name: NH Coal Mining Slurry Pump

-Pump Type: Centrifugal Heavy Duty

-Drive Type: ZVz/CRz/CV/DC

- Power: Motor/Diesel

-Discharge Size: 1 to 18 inch

-Capacity: 0-5000(m3/h)

-Head: 0-70(m)

For example: 6/4E-NH

6:------------Suction diameter (inch)

4:------------Discharge diameter (inch)

E:-----------Base type

NH:---------Heavy abrasive slurry pump

Heavy abrasive slurry pumps structure:

Single stage, single suction, overhang shaft, centrifugal, double-casing horizontal pump,wet ends are made of abrasive resistant hard metal or rubber.

Base - High strengthened base is connected with Frame Plate by bolts; The Adjusting Bolt under the Bearing Assembly realize easy adjustment to impeller clearance.

Bearing Assembly:

-High rigidity shaft to handle heavy duty work condition;

-Cartridge bearing assembly jointed with base by bolts;

-Grease Lube bearings fitted in sealed bearing housing, the two labyrinth on both ends prevent the grease from contamination.

Shaft Sleeve - Clearance fit between solid solution treated stainless steel shaft sleeve and shaft as well as the O-rings on both ends prevent the shaft from abrasion and erosion.

Casing - Made of Gray Iron or Ductile Iron, Ribs help casing to stand high pressure.

Impeller - Pump out vanes on both shrouds reduces recirculation and seal pressure.

Wet Ends - Impellers, liners, volutes made of High-Chrome alloy or rubber, both materials are interchangeable.

Heavy abrasive slurry pumps features:

1). Cantilever, horizontal centrifugal slurry pump

2). Better wear-resistance and corrosive resistance

3). Frame plate for type pumps have replaceable wear-resistant metal ( high chrome alloy ) liners or rubber liners. Impeller material : high chrome alloy or Natural rubber .

4). In allowable pressure range, it can be used in series in stages, and allowable

maximum working pressure is 3.6Mpa.

5). Expeller seal, mechanical seal and packing seal are available .

6). The discharge branch can be positioned at interval of 45 degrees by request and oriented

to any eight positions to suit installations and applications.

7). To adapt to convey heavy abrasion, high concentration dreg , slurry pump's body is

used double-deck construction , in other words, being made of inside lining and outside shell.

Heavy abrasive slurry pumps performance:

Heavy abrasive slurry pumps applications:

Our products are widely used in metallurgy,mining, Nonmetallic mining,Coal,Energy resources, Sand mining, Dredging, Environmental protaction, Petrochemical engineering,Flue gas desulfurization and other industrial departments.

slurry pumps pictures:

NNT Pump company introduction:

NNT pump is specialized in the manufacture and sales of slurry pump and pump parts, especially the design and manufacture of products made with high abrasive, anti corrosive rubber material, including NH(R).M.HH.SP(R).G series slurry pump, WN series dredging pump.......Also can OEM pump parts.

The products are widely used in mining, power, metallurgy, coal, dreading, building material and other Industrial lines to pump concentrate, tailings, sludge and other abrasive, high density slurries.

The quality management systems of Nainater slurry pump are accredited to ISO 9001:2000 and our environmental management systems are accredited to ISO 14001:2004.
