Product Description
Product Description
Product Introduction
IS series single-stage end-suction centrifugal pump is an energy-saving pump designed by teamwork in the whole nation. Its hydraulic capability is distributed reasonably, wide option for user, conveniently check and repair, the efficiency and throw is up to advanced international level. This pump is suitable for industrial and city water supply, water drainage, and widely used for agricultural irrigation, transportation pure water or other liquids which physical and chemical nature is similar to pure water. (IS:temperature not exceeding 80℃ , ISR: temperature not exceeding than 150 ℃)
| Type | Flow Rate | Head | Media | Application | Other characteristics |
| IS65-50-125 |
Min.:15m3/h | Min: 18m | Clean water |
Seawater Pumping |
Horizontal |
| Max.:30m3/h | Max:22m |
Please Let Us Know You
MIS End Suction Water Pump Series
• High efficiency Single-stage
• Durable, low noise, long life bearing
• Premium quality mechanical seal
• Electric or diesel drive
Specification
| No. | Type | Speed | Flow | Head | Power Kw | Eff | NPSHr | Impeller |
| |
|
rpm | m3/h | m | Shaft Motor | % | m | mm |
| 1 | ISISR50-32-125 | 29001450 | 12.56.3 | 205 | 1.13 2.20.16 0.55 | 6054 | 22 | 130130 |
| 2 | ISISR65-50-125 | 29001450 | 2512.5 | 205 | 1.97 30.27 0.55 | 6964 | 2.52 | 130130 |
| 3 | ISISR80-65-125 | 29001450 | 5025 | 205 | 3.63 5.50.48 0.15 | 7571 | 32.5 | 137137 |
| 4 | ISISR100-80-125 | 29001450 | 10050 | 205 | 7 110.91 1.5 | 7875 | 4.52.5 | 139139 |
| 5 | ISISR125-100-200 | 29001450 | 200100 | 5012.5 | 33.6 454.48 7.5 | 8176 | 4.52.5 | 216216 |
| 6 | ISISR150-125-250 | 1450 | 200 | 20 | 13.5 18.5 | 81 | 3 | 262 |
| 7 | ISISR200-150-250 | 1450 | 400 | 20 | 26.6 37 | 82 | 4.6 | 199 |
| No. | Part Description | Material Specification |
| 1 | Pump Casing | Cast Iron |
| 2 | Pump Cover | Cast Iron |
| 3 | Impeller | Cast Iron |
| 4 | Shaft | 45# Steel* |
| 5 | Sealing ring | Cast Iron |
| 6 | Impeller nut | Cast Iron |
| 7 | Lock washer | Cast Iron |
| 8 | Shaft sleeve | Cast Iron |
| 9 | Packing gland | Graphite |
| 10 | Packing ring | Cast Iron |
| 11 | Packing | Cast Iron |
| 12 | Bearing Assembly | Cast Iron |
| |
Bolts | Zinc Plated Steel |
•Domestic water boosters
•Sprinkler/Firefighting
•Water treatment plants
•Seawater pumping
•Chemical / Processing
•Food processing
•Irrigation
•General water transfer
