Electric Centrifugal pump multi stage water pump for house cheap prices

Applications

Centrifugal vertical and horizontal multistage water pumps able to develop high pressure and a high water lift with a comparatively low power consumption.

Universal pump for civil and industrial purposes, for high pressure system and for irrigation in agriculture and sports fittings.

Operating Limits

-Maximum operating pressure: 9 bar.

-Maximum ambient temperature:+40℃.

-Liquid temperature up to +90℃.

-Maximum altitude +1000m.

Design Features

-Stage casing:AISI304 Stainless steel.

-Diffusers:PPO or General Electric Noryl

-Impeller: PPO or “General Electric” Noryl

-Suction casing:cast iron

-Motor shaft:AISI304 Stainless steel

-Mechanical seal: NBR/Graphite/Ceramic.

Motor

-Single phase power supply with capacitor permanently activated.

-Insulation class: B -Protection: IP44

-Speed of rotation: 2850rpm

-Continuous duty: S1

Production Standard

-IEC 60034-1

-IEC335-1

-IEC34-1

-ISO2548

Ser.No.

Part Name

Ser.No.

Part Name

Ser.No.

Part Name

1

plastic cover

14

Mechanical seal

27

Screw

2

Pump body

15

Mechanical seal

28

Self-locking nut

3

O ring

16

Front Cover

29

Pressing block

4

Flange

17

O ring

30

Cable Seal

5

Motor Tie rod

18

Drain Plug

31

Cable pressor

6

Copper plate

19

Screw

32

Capacitor

7

O ring

20

Splashguard

33

Terminal box cover

8

O ring

21

Bearing

34

Spring washer

9

Dos Shell

22

Rotor

35

Tie Bolt

10

Self-locking nut

23

Stator

36

End motor cover

11

Copper plate

24

Terminal box

37

Fan

12

Impeller

25

Terminal block

38

Fan cover

13

Diffuser

26

Flat gasket

39

Screw
